| Size |
150x67x25 mm (5.9″x 2.6″ x 1″) |
Communication |
| Weight |
9.2 ounces (260 grams) |
Audio |
Speaker/ Mic/ Headset jack / Built-in vibration function |
| Processor |
Marvell PXA320 806MHz |
PAN |
BT Class 2, 2.0 EDR |
| Memory/Disk |
256 MB SDRAM/512MB ROM (Flash) |
Cellular (WWAN) |
GSM/GPRS/EDGE, UMTS/HSDPA |
| Operating System |
Microsoft Windows Mobile 6.5 Professional |
Wireless LAN |
802.11 b/g supports AES, TKIP, WEP, WPA, WPA2 |
| Screen |
2.8″ QVGA (320×240) with touchscreen, sunlight readable |
Navigation |
Embedded GPS, G-Sensor, E-Compass, Altimeter |
| Keypad |
Numeric keypad with 20 backlit alphanumeric keys plus function keys on side |
Camera |
3 megapixel camera with autofocus and LED Flash |
| Battery |
3300 mAh Li-Ion |
Barcode Scanner |
1D Laser scanner as standard, optional 2D Imager |
| Connections |
USB port Client 1.1Charger20 pin headset jackDocking Connector (Contact Pin Type) |
Options |
Desktop cradle-Quad dock-Vehicle cradle-Carry cases |
| Environment |
| Operating |
-20 °C to 60 °C (-4 °F to 140 °F) MIL-STD-810G, Method 501.5 Procedure II, MIL-STD-810G, Method 502.5 Procedure II, III |
Storage |
-30 °C to 60 °C (-22 °F to 140 °F) MIL-STD-810G, Method 501.5 Procedure I, MIL-STD-810G, Method 502.5 Procedure I |
| Drop |
26 drops from 1.8 m (6 ft) MIL-STD-810G, Method 516.5, Procedure IV |
Sand & Dust |
IP65, MIL-STD-810G |
| Vibration |
MIL-STD-810G, Method 514.6 Procedure I |
Water |
IP65, MIL-STD-810G |
| Humidity |
MIL-STD-810G, Method 507.5 |
Altitude |
4572 m / 15.000 ftMIL-STD-810G, Method 500.5 Procedure I |
